12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification

I'm Online Chat Now
Certification
China Nanjing Stone Power CO.,LTD certification
China Nanjing Stone Power CO.,LTD certification
We are glad to get your goods about 500kva. the quality is good, our client is satisfy with it, it was really a good cooperation!

—— Pattawit

We are from spain, we visit this facotory and bought 2 gensets from them, we used for a several months, the quality is good, nice cooperation!

—— Rodrigo Calabrano

12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification

12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification
12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification 12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification 12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification 12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification

Large Image :  12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification Get Best Price

Product Details:
Place of Origin: CHINA
Brand Name: SUTONG
Certification: CCS
Model Number: CCFJ-500J5
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Plastic package. LCL, 20FT , 40FT , 40HQ are available, according your order quantity
Delivery Time: 30
Supply Ability: 100 SET/month
Detailed Product Description
Prime Output Power:: 500kw/6250kva Stamford Alternator Model:: HCM 634G
Governor Type:: ELECTRIC TYPE DRIVE ENGINE:: KTA38-DM
Fuel Consumption At Rated Power:: 120 L/H Frequency:: 50 Hz
High Light:

portable marine generator

,

marine diesel genset

CCS Certification Diesel Generator 500KW 625KVA Marine diesel generator powered by Cummins KTA38-DM Engine



Cummins series marine main generator set and emergency set are provided, the power range from 20KW TO 1600KW, compact unit is easy to install, with low fuel consumption, good dynamic performance, high efficiency. The ship certificate of CCS, BV,NK or other major classification society can be provided.

Diesel generator Details
Model CCFJ-500J5
Power 500kw/625kva
Frequency 50Hz
Voltage 400/230v(voltage can be customized)
Optional Type Open/soundproof/trailer
Size of Open type 4100*1230*2330mm
Weight of Open type 6100kg

With Diesel Engine
Brand&model KT38-DM
Rated Power 560kw
Cylinders 12 in V
Bore*Stroke 159*152mm
Displacement 38L
Lubrication Oil Capacity 50L
Fuel Consumption at 100% Load 120L/H
Speed Governor Electronic

With Alternator
Optional Brands Stamford/Leroy Somer/Marathon
Exciter type Single bearing,brushless,Self-excited
Power factor 0.8
Voltage adjust range ≥5%
Insulation Grade H
Protection Grade IP23

Standard equipment
· Diesel engine · Heat Exchanger
· Alternator · Silencer and flexible exhaust hose
·Steel base frame · Engine control meter

Optional equipment
· Sound proof · Water cylinder heater
· 50℃ water cooled radiator · Engine self start control meter




STANDARDS

● GB/T13032-1991, ISO9001:2008 and CE Quality Control System

● As to Classification Society, we will supply CCS as standard; ABS, BV, DNV or RL are option

STANDARD CONTROL PANEL



*engine start/stop
*engine coolant temperature

*oil pressure and temperature

*tachometer
*coolant temperature alarm

*oil pressure alarm
*battery charging indicator
*generator to be protection from overload and overheat






Engine Feature

1. Diesel, heavy-duty, four stroke, water cooled and direct injection fuel system
2. 24/12V D.C starter and charger alternator
3. Industrial capacity exhaust silencer supplied loose with flexible section

4. Engine driven cooling fan with protection guard

5. Steel wire braided fuel lines, vent and rain fittings

6. Set mounted acid battery installed with leads and terminals

7. Noise level: 65dB to 75DB from 7meter away

Alternator Feature

1. Brushless self excited, single bearing, 4 poles
2. Class H insulation
3. IP21/23 protection standard
4. Self-exciting and self-regulating

5. Automatic voltage regulator (AVR)

6. Phase: 3-phase, 4-wire

7. Connection: Y or other type connection

8. Rated speed: 1,500rpm / 1,800rpm

9. Excitation: harmonic excitation or phase compound or brushless

10. Voltage regulation: automatic

11. 1.0% voltage regulation (max.) in static conditions

12. Protection class: IP 22 or IP23

13. Connect with engine:Direct coupled with flywheel

Control System

1. manual / auto start and protection module
2. Equipped with Deep Sea,ComAp,Harsen,Smartgen famous control systems.

3. New integrated controllers in manual and remote start application.

4. Featuring full gen-set monitoring and protection.

5. Powerful graphic display, Icons, symbols and bar graphs

6. High functionality set new standards in gen-set control.

7. Special low temperature version is also available.

8. With AMF control panel or with ATS (automatic transfer system)

9. With EPA certification



Packing

Wooden case or plywood case



Warranty

Warranty:Guarantee for one year or 1200hours from ex-factor date.During the repair time,we will provide the free easy-damageable spare arts of diesel engine caused by our quality of production or raw material.After expiration,we will supply cost spare part for you to repair it.



12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification 0

12 Cylinder marine diesel genset 120 L/H Fuel Consumption CCS Certification 1





Our Adervantage:



1. We are the original supplier of CCEC engine assembly and engine parts.



2. We can give strong technical support.



3. We can matching the engine assembly and parts quickly and accurately.



4. We can produce according to the special requirements of the customers.





FQL:



Q1. Can you provide technical support?

A: Yes, As an OEM branch of CCEC, we can provide strong technical support for you. and we can

provide other brands of generators and lister.



Q2: If I only had the engine NO, Can you find the matching parts quickly for me?

A: Yes, we are equipped with CCEC QuickService Online System that enables us to provide information of CCEC engine assembly and parts quickly and accurately.



Q3: How long is the production time of the goods?

A: We have a lot of regular inventory of the parts, it will take 3-7 days after receiving your advance payment. and the engine assembly delivery time depends on the items and specification of customers.



Q4: What is your terms of payment?

A: T/T 30% as deposit, and 70% before delivery. We will show you the photos of the goods and packages before you pay the balance.



Q5. What is your packing method?

A: Generally, the engine assembly is packed in wooden case, the parts is packed in carton. And we can also according to customers requests.
