Home ProductsWeichai Diesel Generator Set

Weichai Diesel Engine Generator Set Canopy Container Specifications 28KVA / 22KW 25KVA / 20KW

I'm Online Chat Now
Certification
China Nanjing Stone Power CO.,LTD certification
China Nanjing Stone Power CO.,LTD certification
We are glad to get your goods about 500kva. the quality is good, our client is satisfy with it, it was really a good cooperation!

—— Pattawit

We are from spain, we visit this facotory and bought 2 gensets from them, we used for a several months, the quality is good, nice cooperation!

—— Rodrigo Calabrano

Weichai Diesel Engine Generator Set Canopy Container Specifications 28KVA / 22KW 25KVA / 20KW

Weichai Diesel Engine Generator Set Canopy Container Specifications 28KVA / 22KW 25KVA / 20KW
Weichai Diesel Engine Generator Set Canopy Container Specifications 28KVA / 22KW 25KVA / 20KW Weichai Diesel Engine Generator Set Canopy Container Specifications 28KVA / 22KW 25KVA / 20KW Weichai Diesel Engine Generator Set Canopy Container Specifications 28KVA / 22KW 25KVA / 20KW

Large Image :  Weichai Diesel Engine Generator Set Canopy Container Specifications 28KVA / 22KW 25KVA / 20KW Get Best Price

Product Details:
Place of Origin: CHINA
Brand Name: Leroy Somer/Weichai/Stone Power
Certification: CE, ISO9000
Model Number: SW25M5
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: $2450~$3400
Packaging Details: plastic film or wooden case
Delivery Time: 18~42DAYS
Payment Terms: T/T
Supply Ability: 69-99 units per month
Detailed Product Description
Frequency: 50/60 Hz Fuel Consumptiont: 5.2 L/h (average)
Output Voltage: 400V/230 Phase Aspiration: NA
Start Mode: DC 24V Electric Start Rated Currencycy(amps): 36
Standby Power: 28KVA/22KW Protection: Low Oil-pressur, High Water Temperature
Displacement: 2.3L
High Light:

25KVA Canopy Container

,

28KVA Weichai Diesel Generator Set

,

Weichai Engine Canopy Container

Generator set Model No. SW25M5
Standby power 28KVA/22KW
Rated power 25KVA/20KW
Output voltage 230/400
Rated speed (r/min.) 1500
Noise level(7m) 72dB (silent type)
Power factor COSΦ=0.8(lagging)
Phase/wires 3-phase 4-wire
Start mode Electric
Fuel consumption 5.2L/h (Average)
Rated currency(amps) 36
Protection Low oil-pressure, High water temperature, Over-speed, Over-current.
Engine Brand Weichai
Model WP2.3D25E200
Original: China
Cylinders 4
Fuel 0# light diesel
Inter-Cooling N/A
Compression Ratio 17.5:1
Engine Power (prime/standby) 23KW/25KW
Aspiration NA
Governor/Class Mechanical
Bore and stroke 89×92 mm
Start mode DC24V electric start
Cylinders Layout In Line
Displacement 2.3 L
Alternator Brand Leroy Somer
Model TAL-A40-G
Protection IP23
Frequency fluctuation ≤±0.5 %
Voltage distortion <4%
Prime Power 27.5KVA(22KW)
Original China
Rated voltage 400/230 V
Frequency regulation ≤±0.5 %(stable)
Voltage control AVR



Technical parameters of Control Panel:
Brand Smartgen Model 6110 Weichai Diesel Engine Generator Set Canopy Container Specifications 28KVA / 22KW 25KVA / 20KW 0
Function:

• Start or Stop Generator set manually / automatically

• Open controller output can be defined as Pre-heat/Idle output

• High Coolant temperature protection

• Low Oil pressure protection

• Over load protection

• Generator over/under frequency protection

• Generator over/under/unbalance voltage Protection

• Over speed protection

• AMF

Note:Indicate this function depend on the set points of the controller in field.



Standard Accessories Open type Silent type
Sound-proof & Weather-proof Canopy N/A
Daily base fuel tank. 8 hours capacity Option
Single-bearing generator again drops
Intelligent LED display control panel
Speed governor
Electric start and 12v charger
Standard air filter, oil filter, fuel filter
Cooling water tank
High-efficient silencer.
Circuit breaker
Exhaust elbow
Storage battery
Steel base-frame against vibration
Soft pipe for fuel and handle for lube going-out
Operation& Maintenance manual.
Optional accessories
Engine • Heater • Battery Charger
Alternator • Permanent Magnet Generator(PMG)
Control system • Remote Control Panel • Auto Transfer Switch (ATS) • Paralleling System
Fuel system • Daily Fuel Tank • Water Separator • Fuel Level Sensor
Others • Rainproof Type • Soundproof Type • Trailer Type • Extra spare Parts



Rated output 400kw/500kva weichai engine leroy somer alternator high quality soundproof genset



Why to choose weichai diesel generator?As weichai is one of the biggest diesel engine manufacture in the world now,sold more than 1 million units diesel engines in 2021 And its products are exported to more than 110 countries and regions.

Weichai has global after service network all over the world and enjoy global warranty.

Our Weichai generator adopt original Weichai engine and Stafmord/Marathon/Leroy Somer,etc alternator,with high quality and good price.





FAQ:

Q1:How about the warranty of weichai series diesel generator set?



Stone Power provides a full line of brand new and high quality products. Each Genset is strictly factory tested before delivery.

We offer client warranty of 12 months or 1,000 running hours warranty which comes first (longer warranty period can be offered with extra charge)

Weichai engine and Stamford/Marathon/Leroy Somer alternator also enjoy worldwise after service offered by their global after service network.

Quick after service and parts are available from Stone Power or distributors in your location.



Q2:If I want to visit your factory,how can I get?



Welcome to visit our factory,our factory located in Nanjing City,China,about 1 hour by car from Nanjing Airport or South Nanjing railway station.We can pick you up at Nanjing Airport or railway station.
