Home ProductsCUMMINS Diesel Generator Set

8 Hours Fuel Tank CUMMINS Diesel Generator Set Powered by Diesel for IP23 Protection Grade

I'm Online Chat Now
Certification
China Nanjing Stone Power CO.,LTD certification
China Nanjing Stone Power CO.,LTD certification
We are glad to get your goods about 500kva. the quality is good, our client is satisfy with it, it was really a good cooperation!

—— Pattawit

We are from spain, we visit this facotory and bought 2 gensets from them, we used for a several months, the quality is good, nice cooperation!

—— Rodrigo Calabrano

8 Hours Fuel Tank CUMMINS Diesel Generator Set Powered by Diesel for IP23 Protection Grade

8 Hours Fuel Tank CUMMINS Diesel Generator Set Powered by Diesel for IP23 Protection Grade
8 Hours Fuel Tank CUMMINS Diesel Generator Set Powered by Diesel for IP23 Protection Grade
video play

Large Image :  8 Hours Fuel Tank CUMMINS Diesel Generator Set Powered by Diesel for IP23 Protection Grade Get Best Price

Product Details:
Place of Origin: China
Brand Name: Stone Power
Certification: CE;BV;ISO;Soncap
Model Number: SC500E5A
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: plastic film
Delivery Time: 25 days
Payment Terms: T/T or LC
Supply Ability: 50 units per month
Detailed Product Description
Prime Power: 400KW/500KVA Speed: 1500/1800rpm
Cooling System: Closed Water Cooling System Protection Grade: IP23
Warranty: 1 Year Noise Level: Low Noise Level
Alternator: Stamford S5L1D-C4 Fuel: Diesel
Highlight:

IP23 Protection Grade Diesel Generator Set

,

CUMMINS Diesel Generator Set

Product Description:

The CUMMINS 500kVA Diesel Generator Set is a high - performance power generation solution, renowned for its reliability, efficiency, and durability. It is engineered to meet the power needs of various applications, including industrial plants, commercial buildings, construction sites, and emergency backup power systems.



Features:

  • Product Name: CUMMINS Diesel Generator Set
  • Fuel tank: 8 Hours
  • Control System: Automatic Control System
  • Warranty: 1 Year (Global Warranty)
  • Protection Grade: IP23
  • Speed: 1500/1800rpm


Technical Parameters:

Item Parameter
Rated Power (Standby/Prime) 400KW/500KVA(440KW/550KVA))
Rated Voltage 400/230V
Rated Current For the 300kW model, it is 542A
Rated Frequency 50Hz
Rated Rotational Speed 1500r/min
Power Factor 0.8 (Lagging)
Phase 3 - phase 4 - wire
Relative Voltage Regulation Range 0 - 5%
Transient Voltage Regulation - 15% - + 20%
Steady - state Frequency Regulation 0 - 5% adjustable
Transient Frequency Regulation - 7% - + 10%
Voltage Stabilization Time ≤4s
Frequency Stabilization Time ≤3s
Steady - state Voltage Deviation ≤±1%
Frequency Fluctuation 0.5%
Generator Model Optional, such as MX - 300 - 4A (Shanghai Marathon), HC1444F1 (Wuxi Stamford)
Generator Type 3 - phase, 4 - wire, brushless excitation, self - cooling, automatic voltage regulation
Insulation Class H
Generator Efficiency 93% - 93.2%
Unit Dimensions 3250×1420×1660mm
Unit Net Weight 3260kg - 3394kg
Diesel Engine Model KTA19-G3A
Diesel Engine Type In - line six - cylinder, four - stroke, direct - injection
Intake Method Turbocharged, intercooled
Bore×Stroke 140×152mm
Displacement 14L (855 cubic inches)
Standby Power of Diesel Engine 377kW (505BHP)
Prime Power of Diesel Engine 343Kw (460BHP)
Speed 1500r/min
Speed Governor EFC electronic speed governor
Starting Method 24V electric motor starting
Starting Current 600A (>10℃); 640A (0℃ - 10℃)
Fuel Consumption 208g/kW·h
Lubricating Oil Consumption 0.14L/h
Cooling Method Closed - loop cooling system (with fan and water tank) or open - loop cooling system (with heat exchanger)
Control Panel Model Optional, such as RX - 9560 (LCD display control)
Display Function Speed/oil pressure/water temperature/operating hours/current/voltage/frequency/battery voltage/active power
Protection Function High water temperature, low oil pressure, over - speed, over - current, high and low AC and DC voltage, short - circuit


Support and Services:

CUMMINS Diesel Generator Sets come with comprehensive Product Technical Support and Services to ensure optimal performance and reliability. The technical support team is available to assist with installation, maintenance, troubleshooting, and any other product-related queries. Additionally, customers can access training programs and documentation to enhance their understanding of the product.



Packing and Shipping:

Product Packaging:

The CUMMINS Diesel Generator Set is carefully packaged to ensure safe transportation and delivery. Each generator set is securely placed in a sturdy cardboard box with appropriate cushioning to prevent damage during transit. Additionally, the packaging includes clear labeling and handling instructions for easy identification and handling.

Shipping:

We offer reliable shipping services for the CUMMINS Diesel Generator Set to ensure timely delivery to our customers. The generator set is dispatched from our warehouse with a reputable carrier service, and customers can track their shipment using the provided tracking information. We take great care in packaging the product to withstand the rigors of transportation and protect it from any potential damage.



FAQ:

Q: What is the brand name of the diesel generator set?

A: The brand name of the diesel generator set is Cummins Industrial Genset.

Q: What is the model number of the diesel generator set?

A: The model number of the diesel generator set is SC500E5A.

Q: Where is the diesel generator set manufactured?

A: The diesel generator set is manufactured in China.

Q: What certifications does the diesel generator set have?

A: The diesel generator set is certified with CE, BV, ISO, and Soncap.

Q: What are the payment terms for purchasing the diesel generator set?

A: The payment terms for purchasing the diesel generator set are T/T or LC.
