320Kw Weichai Diesel Generator Set with Wattek Alternator 352KW for Standby Power 60 Hz
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Engine Brand: | Weichai | Rated Speed: | 1800r/min |
|---|---|---|---|
| Cylinders Layout: | 6 In Line | Fuel System: | Mechanical Pump |
| Compression Ratio: | 16:1 | Bore And Stroke: | 127×165 Mm |
| Displacement: | 12.54L | Protection: | IP23 |
320Kw Weichai Diesel Generator Set with Wattek Alternator 352KW for Standby Power 60 Hz
320kW Weichai diesel generator set matched with Wattek alternator, with standby power 352kW
and 60Hz as frequency for emergency backup power supply.
| Generator set | Model No. | SW400E6 |
| Standby power | 440KVA/352KW | |
| Rated power | 400KVA/320KW | |
| Output voltage | 440V/254V | |
| Frequency | 60 Hz | |
| Noise level(7m) | 78 dBA (silent type) | |
| Power factor | COSΦ=0.8(lagging) | |
| Phase/wires | 3 phase 4 wires | |
| Start mode | Electric | |
| Fuel consumption |
84.7 L/h (100% load) 63.5 L/h (75% load) |
|
| Max current(amps) | 577 | |
| Protection |
Low oil-pressure, High water temperature, Over-speed, Over-current. |
|
| Engine | Brand | Weichai |
| Model | WP13D385E201 | |
| Rated speed (r/min.) | 1800 | |
| Cylinders layout | 6 in line | |
| Fuel | 0# light diesel | |
| Fuel system | Mechanical pump | |
| Aspiration | Turbo charged and after-cooled | |
| Compression Ratio | 16:1 | |
| Engine Power (prime/standby) | 350KW/385KW | |
| Governor/Class | Electronic | |
| Bore and stroke | 127×165 mm | |
| Start mode | DC24V electric start | |
| Displacement | 12.54L | |
| Alternator | Brand | Wattek |
| Model | WHI 4FS | |
| Protection | IP23 | |
| Insulation class | H | |
| Frequency fluctuation | ≤±0.5 % | |
| Voltage distortion | ＜4% | |
| Output (Cont./standby) | 420KVA/462KVA | |
| Rated speed (r/min.) | 1800 | |
| Rated voltage | 440V/3 phase | |
| Frequency regulation | ≤±0.5 %(stable) | |
| Voltage control | AVR |
| Technical parameters of Control Panel: | ||||
| Brand | Smartgen | Model | HGM 6110N |  |
| Function: | ||||
|
► Manual & automatic start / stop control for generator set ► Programmable output terminals for preheat & idle function ► Shutdown protection against high coolant temperature ► Shutdown protection against low engine oil pressure ► Generator overload protection ► Overfrequency & underfrequency protection ► Overvoltage, undervoltage & voltage unbalance protection for generator output ► Emergency shutdown protection for overspeed fault ► Real-time battery voltage monitoring with high/low voltage alarm ► Cumulative running hours display and historical fault record storage |
||||
| Note:Indicate this function depend on the set points of the controller in field. | ||||
| Optional accessories | |
| Engine | • Heater • Battery Charger |
| Alternator | • Permanent Magnet Generator(PMG) |
| Control system | • Remote Control Panel • Auto Transfer Switch (ATS) • Paralleling System |
| Fuel system | • Daily Fuel Tank • Water Separator • Fuel Level Sensor |
| Others | • Rainproof Type • Soundproof Type • Trailer Type • Extra spare Parts |
| Standard Accessories | Open type | Silent type |
| Sound-proof & Weather-proof Canopy | N/A | √ |
| Daily base fuel tank. 8 hours capacity | N/A | √ |
| Intelligent LCD display control panel | √ | √ |
| Bottom lifting rings | √ | √ |
| Speed governor | √ | √ |
| Electric start and 12v charger | √ | √ |
| Standard air filter, oil filter, fuel filter | √ | √ |
| Radiator | √ | √ |
| High-efficient muffler | √ | √ |
| Circuit breaker | √ | √ |
| Exhaust flexible pipes | √ | √ |
| Storage battery&battery charger | √ | √ |
| Steel base-frame against vibration | √ | √ |
| Soft pipe for fuel and handle for lube going-out | √ | √ |
| Operation& Maintenance manual. | √ | √ |
| Drawing | Dimension |
|
Open type: 3250*1200*2100mm (with fuel tank) 2,800 kg
|
|
Silent type: 4000*1800*2150 mm 4,600 kg
|
Remark:
Prime Power (PRP): Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97(EQV ISO8528); a 10% overload capability is available for a period of 1 hour within a 12-hour period of operation.
Standby Power Rating (ESP): The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
Warranty: Stone Power provides a full line of brand new and high quality products. Each Genset is strictly factory tested before delivery.
We offer client weichai genset warranty of 12 months or 2,000 running hours warranty which comes first
Weichai engine enjoy worldwide after service.
Quick after service and parts are available from Stone Power or distributors in your location.
FAQ:
Q:What is the rated power of this generator?
A:320W / 400kVA diesel generator.
Q:Do you provide CE certificate?
A:Yes, we have CE certificate.
Q:What’s the warranty period?
A:The genset warranty is 12 months or 2000 running hours which comes firstly.
Q:Can we customize the control panel?
A: Smargen or Deepsea is within the optional range.
Q:How long is the lead time?
A:It is to be confirmed in different situations.
